CDM-550H Kydera DMR Mobile Basecamp Radio Digital Car Radio Transceiver
$ 95.99
- Kydera CDM-550H DMR UHF 400-430 440-480Mhz 40W Digital Car Radio Ham Transceiver Product Description Specification: Model CDM-550H Items UHF VHF Frequency Range 400-480MHZ; 350-390MHZ 136-174MHZ; 245MHZ Channel Zone 16 Total Channel Capacity (512) 256 (Analog) 256 (Digital) Digital Mode TDMA T2(DMR) Temperature -20℃- 60℃ Measurement(H*W*D) 140*175*46mm Voltage Rating DC: 13.8V Receiver: Frequency 400-480MHZ; 350-390MHZ 136-174MHZ; 245MHZ Channel Spacing 12.5kHz /25kHZ/6.25kHz Frequency Stability (-20℃, 60℃, 25℃) / – 1.5ppm Analog Sensitivity (12 dB SINAD) 0.3uV / 0.25uV Digital Sensitivity (5% BER) 0.3uV Intermediation 65dB Adjacent Channel Selectivity 60dB 12.5kHz / 65dB 25kHz Spurious Rejection 65dB Rated Audio 2w Audio Distortion Rated Audio 3% FM Hum & Noise -40dB 12.5kHz / -45dB 25kHz Audio Response 1,-3dB Conducted /Radiated Emission -57dBm Transmitter: Frequency 400-480MHZ; 350-390MHZ 136-174MHZ; 245MHZ Channel Spacing 12.5kHz /25kHZ/6.25kHz Frequency Stability (-20℃, 60℃, 25℃) / – 1.5ppm Low Power L: 25W 25W High Power H: 40W 50W Modulation Restriction ±2.5kHz 12.5kHz / ±5kHz 25kHz FM Hum & Noise -40dB 12.5kHz / -45dB 25kHz Conducted /Radiated Emission -36dBm<1GHz / -30dBm>1GHz Adjacent Channel Selectivity -60dB 12.5kHz / -65dB 25kHz Audio Response 1,-3dB Audio Distortion 3% FM Modulation 12.5kHz: 11K0F3E 25kHz: 16K0F3E 4FSK Digital Modulation 12.5kHz Data: 7K60F1D & 7K60FXD 12.5kHz Audio: 7K60F1E & 7K60FXE 12.5kHz Data & Audio: 7K60F1W Digital Vocoder AMBE 2™ Digital Agreement ETSI-TS102 361-1, -2, -3 GPS(Optional) Precisely and standard designed for a long-term positioning( 95% value > could find 5 satellites rated -130dBm signal strength TTFF (time to first fix) cold start < 1 min TTFF (time to first fix) warm start < 10 s Horizontal Position Accuracy < 10 ms Packaging & Shipping –By carton. 1*DMR Mobile car radio transceiver 1*DC Power Cable 1*Bracket 2*Bracket Screw 1*Programming cable(optional) –Bulk order, ship by sea or send radios to your forwarder(free send to Xiamen,Jinjiang etc.); sample, usually ship by DHL,UPS,Fedex.
